‡ 7 ‡
Using the Battery Voltage Tester
1. With the charger unplugged from the AC outlet, connect the charger to the battery
following the instructions given in sections 6 and 7.
2. Plug the charger AC power cord into the AC outlet, following the instructions given in
section 8.
3. If necessary, press the BATTERY TYPE button until the correct type is indicated.
4. Read the voltage on the digital display. Keep in mind that this reading is only a
battery voltage reading; a false surface charge may mislead you.
Power-Up Idle Time Limit: If no button is pressed within 10 minutes after the battery
FKDUJHULV¿UVWSRZHUHGXSWKHFKDUJHUZLOODXWRPDWLFDOO\VZLWFKIURPWHVWHUWRFKDUJHU
if a battery is connected. In that case, the charger will be set to charge at the maintain
mode and gel cell battery type.
Testing After Charging: After the unit has been changed from tester to charger (by
selecting a charge rate), it remains a charger. To change the battery charger back to a
tester, press the CHARGE RATE button until all charge rate LEDs are off.
Fan7KHFKDUJHULVGHVLJQHGWRFRQWUROLWVFRROLQJIDQIRUHI¿FLHQWRSHUDWLRQ,WLVQRUPDO
for the fan to start and stop when maintaining a fully charged battery. Keep the area
QHDUWKHFKDUJHUIUHHRIREVWUXFWLRQVWRDOORZWKHIDQWRRSHUDWHHI¿FLHQWO\
10. MAINTENANCE INSTRUCTIONS
10.1 After use and before performing maintenance, unplug and disconnect the battery
charger (see sections 5, 6 and 7).
10.2 Use a dry cloth to wipe all battery corrosion and other dirt or oil from the battery clips,
cords and the charger case.
10.3 Ensure that all of the charger components are in place and in good working condition,
for example, the plastic boots on the battery clips.
10.4 Servicing does not require opening the unit, as there are no user-serviceable parts.
10.5 $OORWKHUVHUYLFLQJVKRXOGEHSHUIRUPHGE\TXDOL¿HGVHUYLFHSHUVRQQHO
11. MOVING AND STORAGE INSTRUCTIONS
11.1 Store the charger unplugged, in an upright position. The cord will still conduct electricity
until it is unplugged from the outlet.
11.2 If the charger is moved around the shop or transported to another location, take care to
avoid/prevent damage to the cords, clips and charger. Failure to do so could result in
personal injury or property damage.
12. SPECIFICATIONS
Input 230V~50 Hz, 2.3A
Output 6/12V 2A, 10A, 15A
Weight 1.28 kg
Reverse Polarity Protection Yes
Operating Temperature 0°-40° C
13. TROUBLESHOOTING
PROBLEM POSSIBLE CAUSE SOLUTION
CONNECTED LED is
not on.
The battery is not connected
correctly.
Battery voltage is at zero volts.
Check for proper connection to
the battery.
Turn off everything in the car and
try to connect again.
