Operating Manual - XR1001, XR2001, and XR4001 Electronic Crossovers
10
11. WARRANTY INFORMATION
We thank you for expression of confidence in
Ashly products. The unit you have just purchased is pro-
tected by a limited five year warranty. To establish the
warranty, you must first complete and mail the warranty
card attached to your product.
Fill out the information below for your records.
Model Number ______________________
Serial Number _______________________
Dealer _____________________________
Date of Purchase _____________________
Dealer’s Address _____________________
___________________________________
___________________________________
Dealer’s Phone ______________________
Salesperson _________________________
OTHER INFORMATION:
10. SPECIFICATIONS
10.1 Input Level Control
-
∞
to +8.5dB
10.2 Damping/Response
2dB - 12dB
10.3 Output Level Control
-
∞
to +15dB
10.4 Input Impedance
20K
Ω
Balanced
10.5 Output Impedance
200
Ω
Quasi-Balanced
10.6 Maximum Input Level
+23dBu
10.7 Maximum Output Level
+23dBu
10.8 Frequency Response
±
.5dB 20Hz-20KHz
10.9 Distortion
<.05% THD (+10dBu
20Hz-20KHz)
10.10 Slew Rate
6V/
µ
S
10.11 Hum and Noise
<-90dBu unweighted
20Hz-20KHz
10.12 Power Requirements
120VAC 50-60Hz
92VAC Minimum
240VAC Available
15 Watts Max
10.13 Shipping Weight
XR1001: 8 lbs.
XR2001: 10 lbs.
XR4001: 10 lbs.
