Addonics Technologies AE25RDESU User Manual
Page 7
How to build Raid : BIG(Span)
Set the DIP switch as above and Refer to Step b ~ v to build the Raid BIG(Span)
mode. This time you can see only 1 hard disk only(see following two pictures.)
How to build Raid : SAFE50
Set the DIP switch as following and Refer to Step b ~ v to build the Raid SAFE50
mode. This time you can see 2 hard disks ( one is mirror hard disk and the other,
BIG. See following two pictures.
To hard disks
Two healthy hard disks
After Raid SAFE50 is finished, you can see two new hard disks, one is with Raid
mirroring and the other is with Raid BIG.
0
BIG (span)
OFF
OFF
OFF
5
SAFE50
ON
OFF
ON
