Appendix B - Cleaning and Mating Fiber-Optic Systems
LTPS-UM-8013-03
40
August 30, 2002
D3LX CO and RMT Modules
M
ATING
Mate the SC and FC connectors by inserting the connector into the adapter and aligning the connector key with
the adapter key slot as follows:
•
FC connectors—Align the housing key with the slot in the adapter. Push the connector into the adapter and
screw the threaded cap clockwise onto the adapter to complete the connection.
•
SC connector—Align the housing key with the slot in the adapter. Push the connector into the adapter until
a click is heard/felt, indicating that the latching system is engaged. When connector is fully engaged, the white
stripes on the sides of the connector housing should be hidden inside the adapter.
