5-24 Chapter 5: Software support
Rear panel audio ports function variation
The functions of the Line Out (lime), Line In (blue), and Mic (pink) ports on
the rear panel change when you select the 4-channel or 6-channel audio
configuration as shown in the following table.
Adjusting the microphone settings
1. Click on the Microphone Advanced
button to display the Advanced
Controls for Microphone window.
2. Check the box opposite Mic2 Select to
enable the front panel microphone, if
you installed a front panel audio device
such as the ASUS iPanel.
3. Click Close to effect the new setting.
The rear panel microphone is automatically disabled when you enable
the front panel microphone. Only one microphone port works at a time.
Headphone/
2-Speaker
4-Speaker 6-Speaker
Light Blue Line In Line In Bass/Center
Lime Line Out Front Speaker Out Front Speaker Out
Pink Mic In Rear Speaker Out Rear Speaker Out
Windows 98SE only supports 4.1 channel speaker setting.
