Appendix B: Kit Contents
Standalone Gauge Kit (P/N: 3781) - As Shown below
XD-16 Kit (P/N: 3780) – Excludes LC-1, Sensor (P/N: 3737), and Bung/Plug (P/N: 3735). Includes patch cable for
LM-1 (P/N: 3759) – see below)
LM-1 patch cable ((P/N: 3759) – included in kit 3780
LC-1
Quick Start Guide
XD-16
Program Cable (P/N: 3746)
Bung/Plug (P/N: 3735)
Sensor (P/N: 3737)
2.5 to 2.5 Daisy-Chain
Cable (P/N: 3760)
Terminator Plug (P/N: 3750)
Bezel
Gauge Face Kit
XD-16 Hardware Kit
(P/N: 3770)
