USER MANUAL
33014811(1)2005-07 A
21
DIAGRAMS
FUSE POSITIONS
SR 1450 D
(See Fig. AG)
1.
Control unit: 10A
2.
Warning/indicator lights: 7.5A
3.
Diesel solenoid valve: 7.5A
4.
Hazard warning lights: 7.5A
5.
Lighting system: 7.5A
6.
Filter shaker and suction: 20A
SR 1450 B
(See Fig. AH)
1.
Free: 7.5A
2.
Filter shaker-horn: 7.5A
3.
Lights: 10A
4.
Start safety device: 15A
5.
Accessory electromagnetic switch: 15A
6.
Electromagnetic switch-battery charge indicator light:
10A
7.
Power line fuse fitted in the engine compartment:
150A
WIRING DIAGRAMS
SR 1450 D
(See Fig. AI)
A:
14V-45A alternator
AA:
Horn
B:
12V-45A battery
B1:
Glow plug temperature bulb
B2:
Oil bulb
B3:
Reverse gear sensor
B4:
Bimetallic thermostat
C1:
Reverse gear buzzer
C2:
Reverse gear alarm buzzer
CC:
Glow plug control unit
CH:
Ignition switch
CO:
Hour counter
EV:
Diesel solenoid valve
F1:
Control unit fuse
F2:
Indicator/warning light fuse
F3:
Suction-filter shaker fuse
F4:
Diesel solenoid valve fuse
F5:
Horn/light fuse
F6:
Optional hazard warning light fuse
G:
Low fuel float
IAA:
Horn push-button
IE:
Optional hazard warning light switch
II:
Optional turn signal switch
IL:
Light switch
ISV:
Filter shaker-suction switch
I:
Flashing device
L1-4: Optional running lights
L5-6: Optional headlights
L7-8: Optional left side turn signals
L9-10: Optional right side turn signals
M:
Seat safety micro-switch
MA:
Starter
MS:
Filter shaker motor
MV:
Suction motor
R:
Voltage regulator
R1:
Reverse gear buzzer relay
R2:
Fire alarm buzzer relay
S1:
Glow plug warning light
S2:
Battery warning light
S3:
Oil warning light
S4:
Low fuel warning light
S5:
Optional headlight indicator light
S6:
Turn signal indicator light
S7:
Suction indicator light
S8:
Filter shaker indicator light
K1/2: Glow plugs
