USER MANUAL
33014811(1)2005-07 A 9
USE
CONTROLS AND INSTRUMENTS
SR 1450 D
(See Fig. I)
1. Main and side broom rotation lever
2. Hopper lifting lever
3. Skirt closing lever
4. Accelerator lever
5. Parking brake lever
6. Ignition switch
7. Turn signal combination switch
8. Warning switch
9. Fan-filter shaker switch
10. Fan-turn signal indicator light
11. Brake pedal
12. Drive pedal
13. Hour counter
14. Fuse box
15. Glow plug pre-heating-fuel warning light
16. Horn switch
17. Light switch
18. Steering wheel
19. Battery-oil warning light
20. Hopper overheating buzzer (optional)
SR 1450 B
(See Fig. J)
1. Main and side broom rotation lever
2. Hopper lifting lever
3. Skirt closing lever
4. Battery plug
5. Parking brake lever
6. Ignition switch
7. Turn signal combination switch
8. Warning switch
9. Filter shaker switch
10. Battery charge indicator light
11. Brake pedal
12. Drive pedal
13. Hour counter
14. Fuse box
15. Fan switch
16. Horn switch
17. Light switch
18. Steering wheel
19. Turn signal indicator light
20. Hopper overheating buzzer (optional)
Lever controls
The control levers are used for the following functions:
–
Skirt opening;
– Main broom lowering;
– Side broom lowering;
– Hopper lifting;
– Skirt closing;
– Side broom lifting;
– Main broom lifting;
– Hopper lowering.
WARNING!
The machine should be used ONLY by
qualified personnel who know all the machine
controls.
NOTE
Before starting the machine, check the seat
sensor operation: without the operator, the
engine should immediately stop.
