USER MANUAL
8 33014811(1)2005-07 A
SR 1450 B
ENVIRONMENTAL CONDITIONS
Working
The machine should only be used in a suitable environment.
The work environment should be well-lit, should present no
danger of explosions and should be protected from bad
weather conditions.
The machine functions correctly within the following
environmental conditions:
Temperature: +10°C ÷ +40°C.
Humidity: 30% ÷ 95% non-condensed.
Storage
When not in use, the machine should be stored indoor and
protected from bad weather conditions.
Temperature: +1°C ÷ +50°C.
Humidity: maximum 95% non-condensed.
NOISE LEVEL
Measurements were taken in the workplace and around the
machine at a distance of 1 m and at a height of 1.6 m from the
floor level under working conditions.
If the machine is used according to the instructions, the
vibrations do not cause dangerous situations. The machine
vibration level is below 2.5 m/s².
Diesel engine Values
Make Lombardini
Type LDW 702
Cylinders 2
Displacement 686 cm 3
Bore 77.6 mm
Stroke 62 mm
Maximum speed 2,500 rpm
Maximum speed (in running condition) 2,500 rpm
Maximum power 10,2 kW
Idle speed 900 rpm
Battery 12 V 44 Ah
General data Values
Weight in running conditions (without
operator)
630 Kg + 395 Kg
Length 1,880 mm
Width 1,170 mm
Height 1,470/2,230 mm
Speed 0/13 Km/h
Gradeability 12%
Sweeping range (main broom only) 800 mm
Sweeping range with one side broom 1,150 mm
Sweeping range with two side brooms 1,450 mm
Side broom diameter 550 mm
Main broom length 800 mm
Hopper capacity 115 litres
Hopper maximum load 120 Kg
Dumping height 0/1,420 mm
Filtering system 5 m 2
Tyres 3.00/8
Superelastic wheels 3.00/8
Hydraulic tank 32 litres
Transmission Hydrostatic
Steering Mechanical
Brake Hydraulic
Parking brake Mechanical
Sweeping system Self-levelling device
Controls Hydraulic
Battery 36 V - 320 Ah
Motor Values
Type 36 V
Motor 2.5 kW
Maximum speed 2,100 rpm
Maximum power 2.5 kW
