Dashboard
Fitted on the upper part of the frame and under the steering
wheel, the dashboard houses the machine warning lights and
instrumentation.
Hydraulic system
In the first circuit a variable delivery pump feeds the drive
hydraulic motor (rear wheel). In the second circuit a gear
pump feeds a lever double-acting distributor. The distributor
operates the lifting cylinders and the broom motors. All
circuits are protected by suction filters and safety valves.
Electrical system
SR 1450 D: 12 V electrical system supplied by an alternator
operated by the engine. The circuits are protected by lamellar
fuses housed in a relevant fuse box.
SR 1450 B: power electrical system supplied by a 36 V
battery. The service electrical system is supplied by a 12 V
power supply. The circuits are protected by lamellar fuses
housed in a relevant fuse box.
Stability
Machine stability depends on the conditions in which it is
used.
If the machine is used within the conditions of use specified in
the manual, it is stable. To this end, the following tests were
carried out under the same conditions on a prototype identical
to the series model and no stability problems arose. The
conditions were:
Flat ground with good surface conditions:
–
Transfer maximum speed: 13 km/h (SR 1450 D)
Transfer maximum speed: 8 km/h (SR 1450 B)
– Working speed: from 1 to 8 km/h
– Bending radius (maximum speed of 12 km/h): 3 m (SR
1450 D)
– Bending radius (maximum speed of 7 km/h): 3 m (SR
1450 B)
– Bending radius (speed of 5 km/h): 0 m
On sloping ground with good surface conditions and
maximum longitudinal slope of 20%:
–
Bending radius (maximum speed of 5 km/h): 3 m
– Bending radius (speed of 1 km/h): 0 m
Maximum crossfall while in transfer: 15%.
Maximum crossfall at 5 km/h: 20%.
The tests were carried out with lowered and empty hopper.
For different conditions of use, the machine operator should
be able to assess the limits of the machine and should, in any
case, follow the indications laid down in the manual.
Information on brooms
Side brooms (2, Fig. E)
–
Polypropylene side broom
– Polypropylene and steel side broom
– Steel side broom
– Nylon side broom
Main brooms (12, Fig. E)
–
Natural fibre and polypropylene main broom
– Polypropylene main broom
– Polypropylene and steel main broom
– Nylon main broom
Brooms with a moplen shaft or with different bristles can be
supplied on request.
SAFETY SYSTEMS
The machine is provided with an operator's seat sensor that
stops the machine as soon as the operator leaves the seat.
MAIN TECHNICAL DATA
SR 1450 D
General data Values
Weight in running conditions (without
operator)
720 Kg
Length 1,880 mm
Width 1,170 mm
Height 1,470/2,230 mm
Speed 0/13 Km/h
Gradeability 16%
Sweeping range (main broom only) 800 mm
Sweeping range with one side broom 1,150 mm
Sweeping range with two side brooms 1,450 mm
Side broom diameter 550 mm
Main broom length 800 mm
Hopper capacity 115 litres
Hopper maximum load 120 Kg
Dumping height 0/1,420 mm
Filtering system 5 m 2
Diesel engine
Lombardini Focs
LDW 702
Tyres 3.00/8
Superelastic wheels 3.00/8
Fuel tank 10 litres
Hydraulic tank 32 litres
Engine oil pan capacity 1.6 litres
Transmission Hydrostatic
Steering Mechanical
Brake Hydraulic
Parking brake Mechanical
Sweeping system Self-levelling device
Controls Hydraulic
