positive, two for the negative. This will eliminate extra current being carried
over one wire.
Wire Color Code
HTW1000
Terminal Block HTHUB6 Wires CYRON Ribbon lights
Marking / Wire
+12V White +12, 24 / Com / Black
B Black B / Blue
G Green G / Green
R Red R / Red
STEP FIVE: Place the PCBs back in their positions and close the back cover.
Pay close attention to the wires connecting the side PCBs to the main PCB.
STEP SIX: Manage the wires. Use zip ties or other
means to secure the wires together. As stated in the
User Manual, the IR receiver will need to be connected
to the IR plug. The IR receiver needs to be in the line of
sight in order for the remote to work.
Keep the controller and wires away from
extreme heat, liquids, and moving objects.
Low voltage wires can be routed through
walls and cabinets as long as proper care is
taken to avoid damages.
DO NOT modify internal components.
Tampering with components and wiring will
void factory warranty.
