Ashland I-175XL2 User Manual
Page 10
10
PARTS LIST
BOWL and FRAME ASSEMBLY
MODEL I-175XL2 SCRAPER
KEY NO.
PART NO.
DESCRIPTION
1.
A17503
Bowl and Frame, Model I-175XL2 w/Std. Tires
(Consult factory if equipped w/ 29.5 x 25 tire option)
2.
AFB-00094
Bolt: 3/8 NC X 1” Flange Bolt
3.
A10157
Cylinder Guard - Left Hand (to S/N 20495)
A123309-77
“
(from S/N 20496 to S/N 20749)
A123309-62L “
(S/N 20750 and above)
4.
A10158
Cylinder Guard - Right Hand (to S/N 20749)
A123309-62R “
(S/N 20750 and above)
7.
A123332L
Left Cutting Edge
8.
A123330SER
Center Cutting Edge, Serrated 1-1/8” x 12” x 63”
A123330
Center Cutting Edge, Straight 1-1/8” x 12” x 63”
9.
A123332R
Right Cutting Edge
10.
PB9P-NC-088-0275 Plow Bolt: 7/8 NC X 2-3/4” -> 6 Required
11.
AFB-0018
Bolt, 1” NC x 3” long, (5 per Blade Required)
12.
A123357
Bank Shaver/router bit Reversible, L & R
13.
AFN-00012
Nut: 1” NC (5 per Blade Required)
14.
AFN-00019
Nut: 7/8” NC -> 6 Required
15
A125019
Grease fitting 1/4-28 x .54” long (1 per side)
16
A125026
Bulkhead nut 1/8 n.p.s.m. (1 per side)
17
A123309-89
Single hole tab (1 per side)
18
A125022
18” Grease line (1 per side)
