Ashland I-130XL2 Ver 3-2007 User Manual
Page 30
Item #
Part #
Description
1
A125070
Hydraulic Manifold assembly
2
A123391
Hydraulic Tubing, Behind Bowl, around sides
3
A123393
Hydrualic Tubing, Behind Bowl, Around Left Side
4
A123394
Hydrualic Tubing, Behind Bowl, Around Left Side
5
A123405
Hydrualic Tubing, Behind Bowl, Center
6
A123392
Hydraulic Tubing, Behind Bowl, Right Side
7
A123397
Hydraulic Tubing, Gooseneck Arm, Right Side
8
A123399
Hydraulic Tubing, Gooseneck, Straight Piece
9
A123400
Hydraulic Tubing, Gooseneck, Straight Piece
10
A123398
Hydraulic Tubing, Gooseneck Arm, Left Side
H1
A125081
1/2 X 26, High Pressure Hose
H2
A125082
1/2 X 15-1/2, High Pressure Hose
H3
A125022
18” Remote Grease Line
H4
A125084
3/4 X 15, High Pressure Hose
H5
A125085
3/4 X 59, High Pressure Hose
H6
A125086
3/4 X 11-1/2 High Pressure Hose
H7
A125087
3/4 X 19 High Pressure Hose
H8
A125088
3/4 X 67 High Pressure Hose
H9
A125089
1/2 X 20-1/2 High Pressure Hose
H10
A125090
1/2 X 29, High Pressure Hose
H11
A125091
3/4 X 59, High Pressure Hose
H12
A125093
1/2 X 19, High Pressure Hose
H13
A125093
1/2 X 24, High Pressure Hose
H14
A125094
3/4 X 20 High Pressure Hose
H15
A125095
3/4 X 19 High Pressure Hose
H16
A125096
3/4 X 22 High Pressure Hose
H17
A125073
1/2 X 138 High Pressure Hose
A
AHA-00048
90° Swivel 1-1/16 MORB X 1/2 FP
B
AHA-00041
Adapter: STRT. 3/4 M JIC X 1-1/16 MORB
C
AHA-00044
Adapter: 90° 3/4 M JIC X 1-1/16 F JIC
D
AHA-00043
Straight Swivel 1-1/16 MORRB X 1/2 FP
E
AHV-00001
Valve
F
AHA-00015
Adapter:T 3/4 M JIC X 3/4 M JIC
G
AHA-00009
Adapter: T 3/4 F P X 3/4 F P X 3/4 MP
H
AHA-00016
90° Adapter 3/4 MP X 3/4 FP
I
AHA-00010
Adapter: STRT 3/4 M JIC X 3/4 MP
J
AHA-00006
Adapter: STRT 3/4 M JIC X 3/4 MP
K
AHL-00002
Clamp: Hydraulic Tubing:2 tube
L
AHL-00001
Clamp: Hydraulic Tubing: 1 tube
M
AHA-00017
Adapter: Hex Reducer Bushing 3/4 MP X 1/2 FP
N
AHA-00021
Adapeter:45° 3/4 FP X 3/4 MP
O
AHA-00020
Adapter: T 3/4 FP X 3/4 FP X 3/4 FP
P
AHL-00022
Clamp. Hyd Tubing 2 tube stacking
Q
A400H02-S
90° Swivel Adapter 1/2 MP X 1/2 FP
R
A101H72
Straight Swivel 3/4 MP X 3/4 FP
