I-900
Rear Wheel & Hub Assembly
Key Number Part Number Description
1 A9060 Spindle, Rear with flange base plate
2 A8020 Grease Seal (CR 35062)
3 A9061 Bearing Cone, inner
4 A8022 Bearing Cup, inner
5 A8023 Hub
6 A4519 Wheel Bolt, 9/16" NF
7 A8024 Bearing Cup, outer
8 A8025 Bearing Cone, outer
9 A6023 Rear Wheel 24" x 15"
10 A8026 Hub Cap
11 AFP-00002 Cotter Pin, 3/16" x 1-3/4"
12 AFN-00005 Spindle Nut
13 A8027 Spindle washer, special
14 AFP-00001 Bolt, 1" NC x 6-1/2" long
15 AFN-00012 Nut, 1" NC
16 AFW-00001 Flat Washer, 1"
