16
Personal Ambulatory Oxygen System Users Manual
The Eclipse can be used while either discharging or recharging the Battery. It may take
up to 5.0 hours, dependent upon the flow setting, to achieve 80% capacity from a fully
discharged Battery.
INITIAL BATTERY CHARGING
The new Battery supplied with your Eclipse is not fully charged when it is shipped from the
factory. Before using your Eclipse for the first time, you must first fully charge the Battery.
With the AC Power Supply plugged in, and the Battery correctly installed in the Power
Compartment of the device, allow the Battery to completely charge. The Battery is fully charged
when the Power Cartridge Status Gauge, on the Control Panel, is no longer cascading.
To remove the Battery, pull DOWN on the black release lever. While holding DOWN the release
lever, pull the Battery away from the Eclipse.
Battery Operating Times: The duration-of-use of the Battery is displayed at the top of the
Control Panel. A variety of factors, such as flow setting, Pulse or Continuous Flow Mode and
breath rate, will impact the operating time. The table on page 15 provides operating time
ESTIMATES for the Eclipse using a new, fully charged Battery based on flow settings and
operating conditions as indicated.
STORE IN A COOL AND DRY LOCATION TO HELP ENSURE THE LONGEVITY OF YOUR BATTERY.
Rechargeable Power Cartridge (Battery)
Item#7082
CAUTION:
RECHARGEABLE POWER CARTRIDGE (Battery): The Eclipse can be powered by the recharge-
able Power Cartridge (Battery), which is supplied with the device.
Installing the Battery: Align the Battery so that it will slide into the empty Power Compart-
ment. Push the Battery into the empty Power Compartment until it locks (clicks) into position
and is flush with the back of the device. When the Battery is properly installed and the Eclipse is
ON, the Battery Status Gauge will appear on the Control Panel. (If you DO NOT have a Battery
installed, the Power Cartridge Status Gauge will not illuminate).
