1. Make sure your power supply is securely connected to the FreeStyle
inlet, as shown in Figure 2.
2. Connect the proper DC power cord end to the ACCESSORY
DC IN inlet on the power supply, as shown in Figure 7.
3. Remove the tip of the DC connector by pressing on the tab to expose
the 4-pin connector, as shown in Figure 8.
4. Insert the 4-pin connection to the airline passenger DC outlet
optionally available at your seat.
5. To operate the POC, press the FreeStyle [1], [2], or [3] setting on the
unit’s top panel, as determined by your prescription. To turn the unit
off, press the setting associated with the LED illuminated above it.
AirSep’s FAA-approved FreeStyle enables you to use this POC
in-flight on most commercial airlines around the world. Each
airline establishes its own policy for FAA-approved POC use, as
well as the requirements for, and the availability of, optionally
allowing you to power your unit onboard the aircraft. Aircraft-
equipped passenger power may include one or more of the
following sources: an AC power outlet, a DC power outlet
similar to that typically found in an automobile, or a DC power
outlet with a 4-pin configuration.
If the specific airline on which you are traveling allows you to
connect your POC unit at a seat equipped with a 4-pin DC
power configuration, take the following steps:
Figure 8
Figure 7
For more information on the universal power supply for
FreeStyle or any AirSep product accessories, please
contact your local equipment provider.
Rev. - 06/10 MN168-1
Use with Airline Power at Passenger Seat
(with 4-pin connection configurations)
FreeStyle ™ Universal Power Supply AirSep ® Corporation
Instructions for Use www.airsep.com
