ASUS P8Z77-V LX 3-23
Chapter 3
3.5.8 Network Stack
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Allow BIOS yo switch off some power
at S5 to get the system ready for ErP
requirement. When set to Enabled, all
other PME options will be switched
off.
Back Advanced\ Network Stack >
EFI BIOS Utility - Advanced Mode
Network Stack Disabl Link
Network Stack [Disable Link]
Enables or disables the UEFI network stack. Configuration options: [Disable Link] [Enable]
3.6 Monitor menu
The Monitor menu displays the system temperature/power status, and allows you to change
the fan settings.
Scroll down to display the following items:
Main Ai Tweaker Advanced Monitor Boot Tool
Exit
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
→← : Select Screen
↑↓ : Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
EFI BIOS Utility - Advanced Mode
CPU Temperature +73ºC / +163ºF
MB Temperature +31ºC / +87ºF
CPU Fan Speed 4192 RPM
Chassis Fan 1 Speed N/A
Chassis Fan 2 Speed N/A
Power Fan Speed N/A
CPU Q-Fan Control Enabled
CPU Fan Speed Low Limit 600 RPM
CPU Fan Profile Standard
Chassis Q-Fan Control Enabled
Chassis Fan Speed Low Limit 600 RPM
Chassis Fan Profile Standard
CPU Voltage +0.904 V
3.3V Voltage +3.296 V
Version 2.10.1208. Copyright (C) 2011 American Megatrends, Inc.
5V Voltage +5.040 V
12V Voltage +12.480 V
Anti Surge Support Enabled
F2: Previous Values
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
- Hour / - Minute / - Second
Allows you to set the RTC alarm time. Use <+> and <-> keys to adjust the time.
