3-12 Chapter 3: BIOS setup
Chapter 3
DRAM Voltage [Auto]
Allows you to set the DRAM voltage. The values range from 1.185V to 2.135V with a 0.005V
interval.
According to Intel CPU spec, DIMMs with voltage requirement over 1.65V may damage
the CPU permanently. We recommend you install the DIMMs with the voltage requirement
below 1.65V.
VCCIO Voltage [Auto]
Allows you to set the VCCIO voltage. The values range from 0.735V to 1.735V with a 0.005V
interval.
PCH Voltage [Auto]
Allows you to set the Platform Controller Hub volage. The values range from 0.735V to
1.685V with a 0.005V interval.
• The values of the CPU Manual Voltage, CPU Offset Voltage, iGPU Manual Voltage,
iGPU Offset Voltage, DRAM Voltage, VCCIO Voltage and PCH Voltage items are
labeled in different color, indicating the risk levels of high voltage settings.
• The system may need better cooling system to work stably under high voltage
settings.
VCCSA Voltage [Auto]
Allows you to set the VCCSA voltage. The values range from 0.925V to 1.025V with a 0.1V
interval. Configuration options: [Auto] [+0.1V]
CPU PLL Voltage [Auto]
Allows you to set the CPU and PCH PLL voltage. The values range from 1.80V to 1.90V with
a 0.1V interval. Configuration options: [Auto] [+0.1V]
CPU Spread Spectrum [Auto]
[Auto] Automatic configuration.
[Disabled] Enhances the BCLK overclocking ability.
[Enabled] Sets to [Enabled] for EMI control.
Black Yellow Pink Red
CPU Offset
Voltage
0.005V–
0.060V
0.065V–
0.120V
0.125V–
0.175V
0.180V–
0.635V
iGPU Mode
Voltage
0.005V–
0.035V
0.04V–0.065V 0.07V–0.1V
0.105V–
0.635V
DRAM Voltage
1.20000V–
1.57500V
1.58125V–
1.65000V
1.65625V–
1.72500V
1.73125V–
2.20000V
VCCIO Voltage
0.80000V–
1.10000V
1.10625V–
1.15000V
1.15625V–
1.20625V
1.21250V–
1.70000V
PCH Voltage
0.80000V–
1.10000V
1.11000V–
1.15000V
1.16000V–
1.20000V
1.21000V–
1.70000V
