ASUS P8Z77-V LX 2-3
Chapter 2
Connectors/Jumpers/Slots Page
1. CPU, Chassis and power fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1/2, 3-pin PWR_FAN)
2. EATX power connectors (24-pin EATXPWR, 8-pin EATX12V)
3. Intel ® CPU socket
4. DDR3 DIMM sockets
5. GPU Boost LED
6. GPU Boost Switch
7. MemOK! button
8. DRAM LED
9. USB 3.0 connector (20-1 pin USB3_56)
10. Onboard LED (SB_PWR)
11. Intel ® Z77 Serial ATA 3.0 Gb/s connectors (7-pin SATA3G_1–4 [blue])
12. Intel ® Z77 Serial ATA 6.0 Gb/s connectors (7-pin SATA6G_1/2 [gray])
13. System panel connector (20-8 pin PANEL)
14. Clear RTC RAM (3-pin CLRTC)
15. USB connectors (10-1 pin USB5~10)
16. Serial port connectors (10-1 pin COM1)
17. Digital audio connector (4-1 pin SPDIF_OUT)
18. Front panel audio connector (10-1 pin AAFP)
Layout contents
