ASUS USB-N10 Chapter 4: Using the ASUS WLAN Control Center 23
Excellent link quality but not connected to Internet (Infrastructure)
Good link quality but not connected to Internet (Infrastructure)
Fair link quality but not connected to Internet (Infrastructure)
Poor link quality but not connected to Internet (Infrastructure)
Not linked and not connected to Internet (Infrastructure)
Excellent link quality and connected to Internet (Ad-Hoc)
Not linked and not connected to Internet (Ad-Hoc)
Connected to the local area network (LAN) or the Internet
Using the Wireless Settings right-click menu
To use the Wireless Settings right-click menu:
From the Windows ® desktop, right-click the WLAN icon to display the Wireless
Settings right-click menu.
The menu contains the following items:
• Wireless Setting: Click to launch the
Wireless Setting application.
• Activate Configuration: Click to
choose a preset profile.
• Help: Click to launch the help file.
• WPS: Click to launch the Wi-Fi
Protected Setup Wizard.
• About Control Center: Shows the
version of the Control Center.
• Exit: Click to close the Control Center.
