ASUS USB-N10 22
Launching the ASUS WLAN Control Center
ASUS WLAN Control Center is an application that makes it easier
to launch WLAN applications and activate the network location
settings.It starts automatically when the system boots up. When
WLAN Control Center is running, you can see a Control Center
icon on the Windows® desktop.
To launch the ASUS WLAN Control Center, do any of the following:
• Click
Start > All Programs > ASUS Utility > WLAN Card > ASUS WLAN
Control Center.
• From Windows ® desktop, click the ASUS WLAN Control Center icon .
The Control Center taskbar icon displays the following information:
• Link quality of the Network adapter (Excellent, Good, Fair, Poor, Not Linked)
Link quality of the Network adapter (Excellent, Good, Fair, Poor, Not Linked)
• The network connection status (Blue: Connected, Gray: Not Connected) The network connection status (Blue: Connected, Gray: Not Connected)
Taskbar Icon and Status
Wireless Status Icons (on the taskbar)
Excellent link quality and connected to Internet (Infrastructure)
Good link quality and connected to Internet (Infrastructure)
Fair link quality and connected to Internet (Infrastructure)
Poor link quality and connected to Internet (Infrastructure)
Not linked but connected to Internet (Infrastructure)
Chapter 4
Using the ASUS WLAN Control Center
