5.5 COMMUNICATION
This option allows you to configure the status of the RS-232 communication port when connected to an
external device, and the Ethernet communications settings. (Please refer to the RS-232 Protocol and
Network Function for more details)
NET IP:
This option is used to configure the Ethernet communication settings. This is required for the purpose of
making a network connection. Please consult with a qualified MIS professional to configure it.
IP: XXX.YYY.ZZZ.WWW
MASK: XXX.XXX.XXX.XXX
GATEWAY: XXX.XXX.XXX.XXX
NET DHCP:
This option selects CLIENT, SERVER or OFF for the DHCP communication function.
OFF: Disables it.
CLIENT: Disables it.
SERVER: Enables it.
NOTE: The range of available IP to be leased by DHCP server is from XXX.YYY.ZZZ.1 to
XXX.YYY.ZZZ.254 except for NVR’s IP XXX.YYY.ZZZ.WWW.
NOTE: If provided with a DHCP server, the NVR-2018 can get an IP automatically by setting this
option to CLIENT.
LEASED IP TABLE:
Show DHCP leased IP table.
MAIN MENU
LAN CAMERA
RECORD / BANDWIDTH
CLOCK / TIMER / SEQ
ALARM
COMMUNICATION
DISK
SYSTEM
GOTO COMM PAGE
COMM SETTING
NET IP
: SET
NET DHCP : SERVER
LEASED IP TABLE : ENTER
IP POOL RANGE
: SET
COMM ID : 01
RS232 : ON
MAIN PAGE
SET NETWORK
