Reference
Designator
Part
Number
Qty
Part Description
U25-U26
1820-5424
2
IC DRIVER CMOS/74HCT LINE OCTL
U30
1820-4152
2
IC FF CMOS/74HCT D-TYPE POS-EDGE-TRIG
U35
1820-3714
IC TRANSCEIVER TTL/ALS BUS OCTL
U38
1820-4152
IC FF CMOS/74HCT D-TYPE POS-EDGE-TRIG
E1364-80001 1
E1364A TERMINAL MODULE
E1364-66510 1
TERMINAL CARD 16-CH GP RLY SWITCH
E1300-84401 1
TERMINAL CARD, CASE ASSEMBLY
Table 3-2. E1364A Reference Designators
Agilent E1364A Reference Designators
A assembly
P electrical connector (plug)
BRK bracket
PCB printed circuit board
C capacitor
PNL panel
CR diode
R resistor
LBL label
RP resistor pack
F fuse
RVT rivet
J electrical connector (jack)
SCR screw
JM jumper
SHD shield
K relay
SW switch
LBL label
TB terminal block
MP mechanical part
U integrated circuit
