GE 45610WB GE Z-Wave Add On Auxiliary Switch User Manual
Page 9
White (Neutral)
Z-
Wave
45610
Z-Wave
45607,
45609 or
45612*
Black (Line / Hot)
Black
(Load)
Traveler - Colored (Not Green)
Green (Ground)
* The
45612
does not
have a
connection
to Neutral
4-Way Wiring Schematic using two 45610’s and one
45607, 45609 or 45612
Green (Ground)
Traveler - Colored (Not Green)
White (Neutral)
Z-Wave
45610
Black (Line / Hot)
Black
(Load)
Green (Ground)
Z-Wave
45610
Traveler - Colored
(Not Green)
Z-Wave
45607,
45609 or
45612*
* The
45612
does not
have a
connection
to Neutral
SHOCK HAZARD!
Turn
OFF the power to the branch circuit for the switch
and lighting fixture at the service panel. All wiring
connections must be made with the
POWER OFF to
avoid personal injury and/or damage to the switch.
