GE 45610WB GE Z-Wave Add On Auxiliary Switch User Manual
Page 7
Correct Z-Wave switch position for typical 3-way circuit:
Colored (NOT GREEN)
Black
Black
Black
White
Switch 1
Switch 2
Black
(Line / Hot)
Black (Line / Hot)
White
White (Neutral)
Black
(Load)
White
Z-Wave
45610
Z-Wave
45607,
45609 or
45612*
White (Neutral)
Z-Wave
45610
Z-Wave
45607,
45609 or
45612*
Black (Line / Hot)
Black
(Load)
Traveler - Colored (Not Green)
Green (Ground)
Please consult an electrician if you have trouble
identifying the type of wiring circuit you wish to
convert or if you do not feel confident in your ability to
convert the circuit to Z-Wave control.
