ASUS P5MT-S 5-37
5.4.4 Creating a RAID 1 set (Mirror)
To create a RAID 1 set for Fault Tolerance:
1. Follow steps 1 to 2 of the Creating a RAID 0 set section.
2. Select RAID-1 (Fault Tolerance) from the Select RAID Type menu, then
press .
3. Use the arrow keys to select a RAID set member, then press
to mark. An X mark appears after the selected HDD.
4. Follow step 3 to select the other members of the RAID set, then press
when finished.
Refer to the Mirroring Requirements note at the bottom of the screen to
determine the number of hard disk drives required for the selected RAID
type.
