Hardware options installation 38

Advanced ECC population guidelines

For Advanced ECC mode configurations, observe the following guidelines:

Observe the general DIMM slot population guidelines (on page

37

).

DIMMs may be installed individually.

Online spare population

For Online Spare memory mode configurations, observe the following guidelines:

Observe the general DIMM slot population guidelines (on page

37

).

Each channel must have a valid online spare configuration.

Each channel can have a different valid online spare configuration.

Each populated channel must have a spare rank:

o

A single dual-rank DIMM is not a valid configuration.

o

LRDIMMs are treated as dual-rank DIMMs.

Lockstep Memory population guidelines

For Lockstep memory mode configurations, observe the following guidelines:

Observe the general DIMM slot population guidelines (on page

37

).

DIMM configuration on all channels of a processor must be identical.

In multi-processor configurations, each processor must have a valid Lockstep Memory configuration.

In multi-processor configurations, each processor may have a different valid Lockstep Memory

configuration.

Population order

For memory configurations with a single processor or multiple processors, populate the DIMM slots in the
following order:

LRDIMM: Sequentially in alphabetical order (A through H)

RDIMM: Sequentially in alphabetical order (A through H)

After installing the DIMMs, use RBSU to configure Advanced ECC or online spare memory support.

Installing a DIMM

CAUTION:

To avoid damage to the hard drives, memory, and other system components, the air

baffle, drive blanks, and access panel must be installed when the server is powered up.

1.

Power down the server ("

Power down the server blade

" on page

12

).

2.

Remove the server blade (on page

13

).

3.

Remove the access panel (on page

14

).

4.

Remove all DIMM baffles ("

Removing DIMM baffles

" on page

14

).

5.

Locate the DIMM tool ("

Tool locations

" on page

10

) and remove it from the DIMM baffle.
