HP Smart Array P600 Controller for Integrity Servers User Guide
LED ID
Color
LED name and interpretation
4
Green
CR514: Command Outstanding LED. The controller is working on a command
from the host driver.
5
Blue
CR515: Heartbeat LED. This LED blinks every 2 seconds to indicate the
controller health.
6
Green
CR516: Gas Pedal LED. This LED, together with item 7, indicates the amount of
controller CPU activity. For details, refer to the following table.
7
Green
CR517: Idle Task LED. This LED, together with item 6, indicates the amount of
controller CPU activity. For details, refer to the following table.
8
Amber
CR507: Battery Status LED. For interpretation, refer to "Cache module LEDs
(on page
)."
9
Green
CR508: Battery Charging LED. For interpretation, refer to "Cache module LEDs
(on page
)."
10
Amber
CR509: Controller Failure LED. The controller hardware has detected an error.
Controller CPU activity level
Item 6 status
Item 7 status
0–25% Off
Blinking
25–50% Blinking
Off
50–75% On
steadily
Off
75–100%
On steadily
On steadily
