Installing the Adapter
HP NC7770 PCI-X Gigabit Server Adapter User Guide
2-3
Connecting the Network Cable
Network connections for the NC7770 Server Adapter can employ existing Category 5 UTP
(or better) cable for Gigabit over copper transmissions. For new installations, Category 5e
(enhanced Category 5) or better cable is recommended.
To secure the cable, plug the cable connector into the RJ-45 port. Ensure that the tab on the
plug clicks into position indicating that it is properly seated.
For more information, see “UTP Cable Specifications” in Appendix C.
