Front Panel Controls
Table 4-2 Monitor Front Panel Controls
No. Icon Control Function
1 Menu Opens, selects or exits the OSD menu.
2 Volume/Minus If the OSD menu is inactive, press to open the Volume
adjustment OSD sub-menu.
If the OSD menu is on, press to navigate down through the
OSD menu and decrease adjustment levels.
3 Source/Plus If the OSD menu is inactive, press to activate the source
button that chooses the video signal input.
If the OSD menu is on, press to navigate up through the
OSD menu and increase adjustment levels.
4 Auto/OK If the OSD menu is inactive, press to activate the auto
adjustment feature to optimize the screen image.
If the OSD menu is on, press to select the highlighted
menu item.
5 Power Turns the monitor on or off as long as the master power
switch on the rear panel is on.
6 Power LED AquaWhite = Fully powered.
Amber = Sleep mode.
Flashing Amber = Sleep Timer mode.
20 Chapter 4 Operating the Monitor ENWW
