3 Setting Up the Monitor
To set up the monitor, ensure that the power is turned off to the monitor, computer system, and other
attached devices, then follow the instructions below.
Rear Components
HP 2310t Model
Figure 3-1 2310t Rear Components
Table 3-1 2310t Rear Components
Component Function
1 Cable Lock Provision Provides slot for use with cable security locks.
2 AC Power Connector Connects the AC power cord to the monitor.
3 Audio Connector Connects the audio cable to the monitor.
4 HDMI Connector Connects the HDMI cable to the monitor.
5 DVI-D Connector Connects the DVI-D cable to the monitor.
6 USB Upstream Connector Connects the monitor USB cable to a host computer for
touch screen support.
