Hardware options installation 58
6. Remove the PCI riser cage.
Expansion board options
NOTE: This procedure shows images of the SCSI model server, but it also applies to the SAS model server.
The server supports PCI, PCI-X, and PCI Express expansion boards. PCI hot-plug capability is available on
some expansion slots.
NOTE: PCI Express applies only to SCSI models.
For instructions on installing a RILOE II board, refer to the HP Remote Insight Lights-Out Edition II User
Guide on the Documentation CD.
IMPORTANT: It is recommended that the optional RILOE II board be installed in slot 1. If you plan to install
a RILOE II board in the future, leave slot 1 unpopulated.
Removing expansion slot cover 1
1. Power down the server (on page 27 ).
2. Extend or remove the server from the rack (" Extend the server from the rack " on page 28 ).
3. Remove the access panel (" Removing the access panel " on page 29 ).
4. Remove the PCI riser cage (" Removing the PCI riser cage " on page 57 ).
CAUTION: To prevent damage to the server or expansion boards, power down the server and remove all
AC power cords before removing or installing the PCI riser cage.
