Asus P4C800-E - Manual (Page 149)

QUICK
REFERENCE
CARD
PANEL
P4C800-E
®
CPU_FAN
FLOPPY
PRI_IDE
SEC_IDE
PWR_FAN
CHA_FAN
1 2 8
7
5
P4C800-E
ASUS Motherboard
3
6
9
Refer to the Quick Setup Guide
when installing components or
devices for the items indicated
in this reference card.
* Requires an ATX power supply.
PLED-
Ground
PWR
+5V Speaker
Speaker
Connector
Power LED
Ground
Reset SW
SMI Lead
ExtSMI#
Ground Reset
Ground Ground
ATX Power
Switch*
PLED+
IDE_LED- IDE_LED+
IDE_LED
