B321/B421

Information for U.K. only

WARNING – THIS APPLIANCE MUST BE EARTHED.
Important:

(A)

(B)

This apparatus is supplied with an approved moulded 13A plug.

To change a fuse in this type of plug proceed as follows:
1. Remove fuse cover and fuse.
2. Fit new fuse which should be a BS 1362 5A,A.S.T.A. or BSI

approved type.

3. Refit the fuse cover.
If the fitted plug is not suitable for your socket outlets, it should

be cut off and an appropriate 3-pin plug fitted in its place.
If the mains plug contains a fuse, this should have a value of

5A. If a plug without a fuse is used, the fuse at the distribution

board should not be greater than 5A.
NOTE: The severed plug must be destroyed to avoid a

possible shock hazard should it be inserted into a 13A

socket elsewhere.

How to connect a plug

The wires in the mains lead are coloured in accordance with the

following code:

BLUE – “NEUTRAL” (“

N”)

BROWN – “LIVE” (“

L”)

GREEN & YELLOW – “EARTH” (“

E”)

1. The GREEN & YELLOW wire must be connected to the

terminal in the plug which is marked with the letter “

E” or

by the Earth symbol or coloured GREEN or GREEN &

YELLOW.

2. The BLUE wire must be connected to the terminal which is

marked with the letter “

N” or coloured BLACK.

3. The BROWN wire must be connected to the terminal which

marked with the letter “

L” or coloured RED.

Before replacing the plug cover, make certain that the cord grip

is clamped over the sheath of the lead – not simply over the

three wires.
