2
B321/B421
B321:
Protective Sheet
Table
200
100
B421:
Protective Sheet
Table
400
400
1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as
not to scratch the screen face.
2. Ensure you have all accessories for mounting this display.
3. Follow the instructions that come with the base mounting kit. Failure to follow correct mounting procedures could result in damage to
the equipment or injury to the user or installer. Product warranty does not cover damage caused by improper installation.
4. For the wall-mounting kit, use mounting screws and tighten them securely.
Model VESA Size (mm)
Mounting Screws*
(X=Thickness of wall-mount plate)
B321 200 × 100 M6 × (16 + X)
B421 400 × 400 M6 × (20 + X)
Caution:
To prevent the display from falling:
• To lessen the probability of injury and damage resulting from fall of the display in case of earthquake or other natural disaster, be sure
to consult the bracket manufacturer for installation location.
Ventilation Requirements for enclosure locating
To allow heat to disperse, leave space between surrounding objects as shown in the diagram below.
100 mm 100 mm
100 mm
100 mm
NOTES: When installing the display on a wall, please consult a professional technician for proper installation. We accept no liability for
installations not performed by a professional technician.
The display can be installed on a wall and viewed in only the landscape position.
Using the display for more than 14 hours per day may result in image retention damage,which is not covered under the HP
warranty.To avoid image tetention damage,always turn off the monitor when it is not in use.
This product does not support a single image video wall solution.
