Specifications 12
Specifications
Cable specifications
SFP+ modules or
copper cable
Fiber type Cable grade Minimum modal
bandwidth @ 850
nm (MHz-km)
Operating range
(meters)
10GBASE-SR
(short range)
62.5 µm MMF
62.5 µm MMF
50 µm MMF
50 µm MMF FDDI
OM1
OM2
OM3 160
200
500
2000 2 to 26
2 to 33
2 to 82
2 to 300
10GBASE-LRM
(long reach
multimode)
50, 62.5 µm MMF OM1, OM2, OM3 N/A 0.5 to 220
10GBASE-LR
(long range) 10 µm SMF B1.1, B1.3 SMF N/A 2 to 10,000
Direct attached
copper
Twin Axial Copper @26 AWG N/A .5 - 10
General specifications
General
specifications
Value
Controller NETXEN NX3031
Data rate 10Gbps, full-duplex
PCI bus 8 Lane (x8) PCI Express Gen 2, compatible with x4 and x8 bus widths
Connectors 2 SFP+
Dimensions (LxW) 6.6 x 2.7 inches (16.734 cm x 6.85 cm) without bracket
Compliance
Compliance Standard
IEEE IEEE802.3x, IEEE802.3ad, IEEE802.1p, IEEE802.1q, IEEE802.3z, IEEE802.3ae
Safety UL Mark (US and Canada)
EN 60950
