Chapter 1: introduction, Overview, Hardware overview – HP NC3122 Fast Ethernet Server Adapter User Manual
Page 9: Chapter 1, Introduction, Overview -1, Hardware overview -1, Chapter
Chapter
1
Introduction
Overview
The Compaq NC3122 Fast Ethernet Server Adapter has two auto-negotiating RJ-45 ports and
LED indicators showing link, activity, and port speed. The NC3122 Server Adapter is a
supported option for selected Compaq ProLiant™ servers.
For the latest functionality, features, and operating system support for this server adapter, see
the networking page at
compaq.com
Hardware Overview
The NC3122 Server Adapter has two auto-negotiating RJ-45 ports. LED indicators show link,
activity, and port speed. See Table 1-1 for a description of LED operations.
Figure 1-1. RJ-45 ports and LED locations
LNK
ACT
100Mbps
LNK
ACT
100Mbps
Link LED
Activity LED
100 Mbps
Port 2
Link LED
Activity LED
100Mbps
Port 1
