Page 21
Drawer Warmer Installation/Operation/Service Manual • 19.
S E R V I C E
500-3D • Electronic control • top removed • 230V
INSULATION
IN
-2003
CONTROL
CC-34222
WITHOUT
HAACP •
CONTROL
#5000877
WITH
HAACP
ELECTRIC CORD
BREAKER SWITCH
SW
-34769
RELAY
RL
-33558
BEEPER
BP
-3567
POWER SUPPLY
BA
-33554
SENSOR WIRE
(
WHITE
)
HEATING
ELEMENT
CONNECTIONS
AIR TUNNEL
1002672
(
EXHAUST FAN INSIDE
)
TERMINAL BLOCK
THIS PHOTOGRAPH IS AN
ENLARGEMENT OF THE CIRCLED
AREA ABOVE
.
WIRING
DIAGRAM
CORD
BUSHING
BU
-3964
