Overview
The Compaq NC3134 Fast Ethernet Server Adapter is a second-generation, dual-port adapter
that offers improved performance over earlier versions of the product. This improvement is due
to the 64-bit/66MHz PCI-to-PCI bridge, as well as to the enhanced MAC silicon technology not
previously available. The NC3134 adapter supports existing 10/100 Ethernet, 100FX, and 1000
SX/LX upgrade modules, which are listed in Table 1-1. The NC3134 adapter is a supported
option for selected Compaq ProLiant™ servers.
The new NC7132 upgrade module, described later in this chapter, has one RJ-45 connector and
a 10/100/1000 Mb/s port that delivers up to 1000 Mb/s Ethernet over twisted-pair cabling
(Gigabit over copper).
Table 1-1 describes the adapter and upgrade modules.
Table 1-1
NC3134 Adapter and Upgrade Modules with Port and Connection Options
Name Type Number and Types
of Ports
Connection Option
NC3134 Server adapter Two RJ-45 10BASE-T/100BASE-TX
NC3133 Upgrade module One SC fiber 100BASE-FX
NC3135 Upgrade module Two RJ-45 10BASE-T/100BASE-TX
NC6132 Upgrade module One SC fiber 1000BASE-SX
NC6133 Upgrade module One SC fiber 1000BASE-LX
NC7132 Upgrade module One RJ-45 10BASE-T/100BASE-TX/ 1000BASE-T
(Gigabit over copper)
For the latest functionality, features, and operating system support for this server adapter, see
the networking page at
compaq.com
