HP x22LED 21.5 inch Diagonal LCD Monitor - Manual (Page 14)

8
Appendix 4. Operating the Monitor ENWW
Front-Panel Controls
The monitor buttons are located on the bottom of the front panel
Figure 4-1 Front-panel control
button
Hot Key definition:
Auto: Auto configure; Press for 3 seconds, Source select
- : ECO mode select when OSD is not active
+: Image ratio select when OSD is not active
No. Icon Description
1 Power Turns the monitor on or puts it in standby or sleep mode. The Power
depending on the model.
2 Menu Opens, selects, or exits the OSD menu.
3 + Navigates forward through the OSD menu and increases adjustment
levels.
4 - Navigates backward through the OSD menu and decreases adjustment
levels.
5 Auto To utilize the auto-adjustment feature, press the key and release it
immediately. To use input source selection function, press and hold the
key for 3 seconds (multi-source models).
