Chapter 3. Setting Up the Monitor ENWW
3. Setting Up the Monitor
Unpacking the Monitor
1. Unpack the monitor. Make sure all contents are included. Store the packing box.
2. Turn off the computer and other attached devices.
3. Prepare a flat area to assemble the monitor. You may need a flat, soft, protected
area for placing the monitor screen-down while preparing it for installation.
Installing the Monitor
1. Set the monitor screen face down on a flat, soft, protected table or desk surface
with the support column overhanging the edge.
2. Push the base to the monitor support column and fasten the screw to lock it.
Figure 3-1 Installing the Base
CAUTION: The screen is fragile. Avoid touching or applying pressure to the LCD
screen; doing so can cause damage.
3. Lift the monitor to an upright position and place on a flat, stable surface.
Figure 3-2 Monitor in Upright Position
