Removing or replacing the service doors
Removing the service doors
Remove the service doors to access the memory module slot, hard drive, and other components.
1.
Remove the battery (see
Inserting or removing the battery on page 50
).
2.
With the battery bay away from you, loosen the service door screw (1). The service door screw
secures both service doors.
3.
Slide the larger service door away from the battery bay (2) to remove it.
4.
Slide the smaller service door away from the battery bay (3) to release it, and then lift the service
door (4) to remove it.
NOTE:
Your computer may look slightly different from the illustration in this section.
Replacing the service doors
Replace the service doors after accessing the memory module slot, hard drive, regulatory label, and
other components.
1.
With the battery bay away from you, replace the smaller service door first. Align the vent on the
smaller service door with the vent on the computer, and then slide it toward the battery bay (1).
2.
Press down on the smaller service door (2) until it snaps into place.
3.
Slide the larger service door toward the battery bay (3) until it snaps into place.
