Introduction
1-2
HP NC370F PCI-X Multifunction Gigabit Server Adapter User Guide
LED indicator
The adapter has a single fiber LC port and LED indicator for activity/link.
Figure 1-1: NC370F PCI-X Multifunction Gigabit Server Adapter
The HP NC370F PCI-X Multifunction Gigabit Server Adapter LED indicator operates as
described in the following table.
Table 1-1: LED operation for the HP NC370F PCI-X Multifunction Gigabit Server
Adapter
LED
Status
Description
Off
No link to the adapter is established. The adapter is not
receiving power or the cable connection is not established.
On
When green, link to the adapter is established. The adapter is
receiving power and the cable connection is secure.
LNK/ACT
Flashing
The adapter is receiving direct packets or broadcast packets for
this specific adapter. When sending packets, the LNK/ACT light
is also flashing due to network acknowledgements received.
