HP Compaq S2021 20-inch Widescreen LCD Monitor - Manual (Page 31)

B Technical Specifications
All specifications represent the typical specifications provided by HP's component manufacturers; actual
performance may vary either higher or lower.
Compaq LCD Monitors
Face treatment: Glare polarizer with hard coating
Input terminal:
VGA connector
●
DVI-D 24–pin D-type connector (select models)
●
Table B-1 Model S1921\S1921d
Specifications:
Display Type: TFT LCD active matrix
Viewable Image Size: 47.0 cm (18.5 in.) diagonal
Tilt –5° to +20°
Swivel
Maximum Weight (unpacked): 2.7 Kg (5.95 lb)
Dimensions (h x w x d): 324 x 446 x 162 mm (12.8 x 17.6 x 6.4 in).
Maximum Graphics Resolution: 1366 x 768 @ 60 Hz
Text Mode: 720 x 400
Dot Pitch: 0.30 x 0.30 mm
Horizontal Frequency :
30 to 64 kHz
Vertical Frequency : 50 to 76 Hz
Environmental Requirements
Temperature (independent of
altitude)
Operating Temperature: 5° to 35° C （41° to 95° F)
Non-Operating Humidity: –20° to 60° C （–29° to 140° F)
ENWW Compaq LCD Monitors 25
