HP Compaq S2021 20-inch Widescreen LCD Monitor - Manual (Page 22)

Figure 4-2 Front-bezel control buttons
No. Icon Description
1
Auto-adjust the display to the ideal setting when the
OSD is not active / Enter the selected option
Pressing the “OK” button for 5 seconds shall be a hot-
key for the Input Select sub-menu. (select models)
2
Hot key to link volume level adjustment / Navigate
forward through the OSD menu and decreases
adjustment levels (Select modes).
3 Hot key to link to volume level adjustment / Navigate
backward through the OSD menu and increases
adjustment levels (Select modes).
4
Open, or select the OSD menu.
5
Turn the monitor on or off.
The Power button is located on the bottom right side of
the monitor.
6
Power LED
Front-Bezel Controls
Control buttons are located on the front bezel of the monitor:
16 Chapter 4 Operating the Monitor ENWW
Light up to indicate the power is turned ON.
