Right
Component Description
(1) Power button Turns power on and off.
(2) Power light ● On: The computer is on.
● Blinking: The computer is in the Sleep state.
● Off: The computer is off.
(3) Rotation lock button Locks screen orientation in either Landscape or Portrait
mode.
NOTE: When you move between notebook and tablet
configuration, the computer screen will automatically
change to vertical or horizontal. To lock the current
screen orientation, slide the screen orientation button.
(4) Volume button Lowers the volume.
(5) Volume button Raises the volume.
(6) Speaker Produces sound.
(7) Digital Media Card Reader Supports a micro SD High Capacity (SDHC) memory card
or an optional wireless micro subscriber identity module
(SIM)
(8) Audio-out (headphone) jack/Audio-in
(microphone) jack Produces sound when connected to optional powered
stereo speakers, headphones, earbuds, a headset, or
television audio. Also connects an optional headset
microphone.
WARNING! To reduce the risk of personal injury, adjust
the volume before putting on headphones, earbuds, or a
headset. For additional safety information, see the
Regulatory, Safety, and Environmental Notices. To
access the user guides, select the HP Support Assistant
app on the Start screen, select My computer, and then
select User guides.
NOTE: When a device is connected to the jack, the
computer speakers are disabled.
NOTE: Be sure that the device cable has a 4-conductor
connector that supports both audio-out (headphone) and
audio-in (microphone).
(9) Docking port Connects an optional docking device.
Right 7
