Recognizing Preset Display Resolutions
The display resolutions listed below are the most commonly used modes and are set as factory defaults.
This monitor automatically recognized these preset modes and they will appear properly sized and
centered on the screen.
HP L5006tm and L5009tm
Table B-5 Factory Preset Modes
Preset Pixel Format Horz Freq (kHz) Band Width (MHz)
1 VGA 640 x 350 70Hz 31.5 28.322
2 VGA 720 x 400 70Hz 31.47 28.322
3 VGA 640 x 480 60Hz 31.47 25.175
4 MAC 640 x 480 66Hz 35.00 32.24
5 VESA 640 x 480 72Hz 37.86 31.5
6 VESA 640 X 480 75Hz 37.50 31.5
7 VESA 800 X 600 56Hz 35.16 36
8 VESA 800 X 600 60Hz 37.88 40
9 VESA 800 X 600 75Hz 46.88 49.5
10 VESA 800 x 600 72Hz 48.08 50
11 MAC 832 x 624 75Hz 49.72 57.283
12 VESA 1024 x 768 65Hz 48.36 65
13 SUN 1024 x 768 65Hz 52.45 70.49
14 VESA 1024 x 768 70Hz 56.48 75
15 VESA 1024 x 768 75Hz 60.02 78.75
Entering User Modes
The video controller signal may occasionally call for a mode that is not preset if:
● You are not using a standard graphics adapter.
● You are not using a preset mode.
If this occurs, you may need to readjust the parameters of the monitor screen by using the on-screen
display. Your changes can be made to any or all of these modes and saved in memory. The monitor
automatically stores the new setting, then recognizes the new mode just as it does a preset mode. In
addition to the 15 factory preset, there are 7 user modes that can be entered and stored.
The only condition to store as a user mode is the new display information must have 1 KHz difference
for horizontal frequency or 1 Hz for vertical frequency or the sync signal polarities are different from the
default modes.
ENWW Recognizing Preset Display Resolutions 25
