Page 26: Btechnical specifications

B
Technical Specifications
NOTE:
All performance specifications are provided by the component manufacturers. Performance
specifications represent the highest specification of all HP's component manufacturers' typical level
specifications for performance and actual performance may vary either higher or lower.
HP L5006tm Touchscreen
Table B-1
HP L5006tm Specifications
LCD Display
Type
38.1 cm
TFT LCD
15 inches
Display Size
304 (H) x 228 (V) mm
12.0 (H) x 9.0 (V) in
Pixel Pitch
0.297 (H) x 0.297 (V) mm
0.01 (H) x 0.01 (V) in
Display Mode
VGA 640 x 350 (70Hz)
VGA 720 x 400 (70Hz)
VGA 640 x 480 (60 / 72/ 75Hz)
SVGA 800 x 600 (56 / 60 / 72 / 75Hz)
XGA 1024 x 768 (60 / 70 / 75Hz)
Maximum Resolution
XGA 1024 x 768 at 75Hz
Contrast Ratio
400 : 1 (typical)
Brightness
Typical 230 Cd/m
2
; Min 184 Cd/m
2
Response Time
Tr: 5 ms
Tf: 12 ms Typical
Display Color
16.2M
Viewing Angle
Vertical -60° ~ +40°
Horizontal -60° ~ +60°
Input Signal
Video
Sync
R.G.B. Analog 0.7Vp-p, 75 Ohms
TTL Positive or Negative
Signal Connector
Mini D-Sub 15 pin
Side Control
Menu, up arrow, down arrow, Select,
Power
20
