Using the On-Screen Display
Use the On-Screen Display (OSD) to display and select OSD menu functions. To access the OSD, do
the following:
1. Press the Menu button on the side panel to activate the OSD menu.
2. Use the up arrow or down arrow controls to move clockwise or counterclockwise through the menu.
Press the Enter key on the keyboard, the parameter will be highlighted when selected.
3. To quit the OSD screen at any time during the operation, press the Menu button. If the OSD remains
untouched for a short period of time, the OSD automatically disappears.
NOTE: The OSD screen will disappear if no input activities are detected for 45 seconds.
OSD Menu Table
The following table lists the On-Screen Display (OSD) menu selections and their functional descriptions.
Settings will be saved automatically after adjustments are made.
Table 4-2 OSD Menu
Icon OSD Control Description
Brightness Increases or decreases brightness.
Contrast Increases or decreases contrast.
H-Position Adjusts the position of the screen image left and right.
V-Position Adjusts the position of the screen image up and down.
Phase Adjusts the focus of the display. This adjustment allows you to remove any horizontal
noise and clear or sharpen the image of characters.
Clock Minimizes any vertical bars or strips visible on the screen background. Adjusting the
Clock will also change the horizontal screen image.
Sharpness Adjusts the screen image to look sharper or soft.
OSD H-Position Moves the OSD position horizontally on the screen. When the up arrow button is
pressed, the OSD menu will move to the right side of the screen. Likewise, when the
down arrow button is pressed, the OSD control menu will move to the left side.
OSD V-Position Moves the OSD position vertically on the screen. When the up arrow button is
pressed, the OSD menu will move to the top side of the screen. Likewise, when the
down arrow button is pressed, the OSD control menu will move to the lower side.
OSD Time Adjusts the amount of time the OSD menu is displayed.
Color Balance Press the up arrow button or the down arrow button to select 9300, 6500, 5500, 7500
or USER. Only when selecting USER can you make adjustments to the R/G/B (red/
green/blue) content. Press Enter to restore the factory default setting.
Auto-Adjustment Press Auto to enable this function. The Auto-Adjustment will automatically adjust V-
Position, H-Position, Clock and Clock-Phase.
Recall Defaults Returns the monitor to its default settings.
ENWW Using the On-Screen Display 13
