Modifying a Tile Mode
The following describes how to modify the previous Tile Mode.
1. Select the Tile tab. The Tile Mode Wizard appears. To modify a previous Tile Mode, select Adjust Tile
Mode.
2. The Tile Mode Summary dialog appears. Modify the Tile Mode as necessary.
Tile Mode Settings
16.9mm to 20.3mm Bezel Models Micro Bezel Models
Identify Size of Matrix Tile Mode: Choose the matrix dimension
(HxW); OFF, 1x2, 1x3, 1x4, 1x5, 2x1, 2x2,
2x3, 2x4, 2x5, 3x1, 3x2, 3x3, 3x4, 3x5, etc.
up to 5x5
H monitors: Enter Number of rows (1, 2, 3,
4, 5) V
Monitors: Enter Number of columns (1, 2,
3, 4, 5)
Identify the display position within the
matrix
Tile ID: Enter the number of the display
within the matrix, start numbering from
the top left, across and then down (1, 2, 3,
4, 5...25)
H Position: Enter column position from left
to right (1, 2, 3, 4, 5)
V Position: Enter row position from top to
bottom (1, 2, 3, 4, 5)
Mullion Compensation Natural Mode: OFF/ON Natural Mode: OFF/ON
Adjust horizontal size of image H Size: 0 to 100 pixels N/A
Adjust vertical size of image V Size: 0 to 100 pixels N/A
Move screen position horizontally H Position: +/- 10 pixels N/A
Move screen position vertically V Position: +/- 10 pixels N/A
Return settings to default Reset: Turns Tile Mode Off Reset: Return all settings to default (1)
Schedule and Playback contents for HP Media Sign Player (USB)
This function allows you to set the playback schedule of HP Media Sign Player. All files to play should be
saved in a USB storage device and then inserted into the USB port on the display. HP Network Sign Manager
allows you to schedule the start and stop time, define the play list, and define the days of the week the play
list should be played. You can have only one schedule and play list defined for the display. See the HP Media
Sign Player User Guide for more details. This function is only active for displays which support HP Media Sign
Player. See Appendix A for a list of these displays.
Scheduling the playback of files
Set the playback schedule for HP Media Sign Player.
USB Schedule
USB Schedule allows you to schedule the playback of media files saved in the USB storage device connected
to the display. USB Schedule has three sections: File List, Play List, and Set Play List Schedule.
NOTE: Screen image content varies based on model.
